The large size of this flow regulator is unique in the industry for precise control of 3/4″ cooling water lines. Brass body, valve stem and seat with EPDM o-rings are compatible with most process liquids. The flow regulator can be used in combination with a 3/4″ mechanical flow meter to add flow, temperature or presssure indiction. InceCube flow body with 8 gpm or 30 lpm scale may be added to display flow rate.
Body – Brass
Valve Stem & Seat – Brass
O-Rings – EPDM
Cap Screws – Stainless Steel
Mounting Brackets – Powder Coated Steel
Optional Flow Indicator Parts
Flow Body – Polysulfone
Vane – Nylon
Spring – Stainless Steel
Thread Size – 3/4″ NPT(F)
Operating Temperature max – 240°F (115°C)
Operating Pressure max – 150 psi (10.3 bar)
